The ZXTC2063E6TA is a cutting-edge bipolar transistor from Diodes Incorporated, designed to offer high efficiency and performance for a wide range of electronic applications. This product is a testament to Diodes Incorporated's commitment to providing high-quality components that meet the rigorous demands of modern electronics.

Key Features

• Transistor Type: The ZXTC2063E6TA is an NPN transistor, which is widely used for amplifying and switching electronic signals.
• Current and Voltage Ratings: It can handle continuous collector currents up to 2A, making it suitable for medium power applications. The collector-emitter voltage rating is at 30V, which allows for a good range of operation for various circuits.
• Power Dissipation: With a power dissipation of 1.25W, this transistor can sustain moderate thermal stresses during operation.
• High Gain Bandwidth Product: The device features a high gain bandwidth product (fT) of 180MHz, providing excellent frequency response for high-speed amplification tasks.
• Package: Encased in a compact SOT-23 package, the ZXTC2063E6TA is optimized for space-saving on printed circuit boards and is suitable for automated surface-mount assembly processes.

Applications

The ZXTC2063E6TA is an extremely versatile component that can be used in various applications, including:

• Driver stages in audio amplifiers
• Signal processing
• Switching regulators
• Power management functions
• DC-DC converters

Quality and Reliability

Diodes Incorporated ensures that the ZXTC2063E6TA meets strict quality standards for reliability and performance. Each transistor is subjected to rigorous testing and quality control measures, guaranteeing that it performs to the specifications under a range of conditions.

Environmental Compliance

Furthermore, the ZXTC2063E6TA complies with RoHS (Restriction of Hazardous Substances) directives, which means it is manufactured with a commitment to environmental safety and sustainability.
