Product Overview: PI5C3384LEX from Diodes Incorporated

The PI5C3384LEX is a high-performance, 10-bit, 2-port bus switch from Diodes Incorporated, designed to provide seamless connectivity and switching capabilities for data and address lines in computing and communication systems. This integrated circuit is part of the PI5C series, known for its low power consumption and high-speed operation.

Key Features

• Low On-Resistance: The PI5C3384LEX features a low on-state resistance of typically 5 ohms, ensuring minimal signal distortion and power loss during switching operations.
• Wide Voltage Range: It operates over a wide voltage range of 4.5V to 5.5V, making it compatible with various logic levels and providing design flexibility.
• Quick Switching: Fast switch times (turn-on and turn-off) of around 0.25ns and 0.15ns, respectively, facilitate high-speed data transmission and reduce latency in critical applications.
• 5V Tolerant: Input and output ports are 5V tolerant when powered off, allowing for interface flexibility with mixed-voltage systems without the risk of damage.
• Low Quiescent Power: Despite its high-speed capabilities, the PI5C3384LEX maintains low quiescent power consumption, which is essential for energy-sensitive designs.
• Industrial Temperature Range: With an operating temperature range of -40°C to +85°C, it is suitable for industrial applications that require robust performance under extreme conditions.

Applications

The PI5C3384LEX is ideal for a variety of applications where efficient data flow control is necessary. This includes:

• High-speed data transfer systems
• Networking equipment such as switches and routers
• Server and computer motherboards
• Signal gating and data multiplexing
• Communication interfaces

Product Specifications

Enclosed in a space-saving LEX package, the PI5C3384LEX is designed for surface mount technology, enabling compact and high-density PCB designs. Its integrated circuitry is optimized for low crosstalk and minimal propagation delay, ensuring reliable performance in high-speed digital environments.

For detailed specifications, technical datasheets, and application notes, visit the Diodes Incorporated website or contact an authorized distributor. The PI5C3384LEX is a testament to Diodes Incorporated's commitment to providing advanced solutions for modern electronic challenges.
