Product Overview

The LM4040C30FTA from Diodes Incorporated is a precision fixed shunt voltage reference that offers a stable reference voltage over a wide range of operating conditions. This device features a nominal voltage of 3.0V and is widely used in various applications, including power supplies, battery-operated equipment, and precision data conversion systems.

Key Features

• Fixed Output Voltage: 3.0V with a tight tolerance level, ensuring consistent performance.
• Low Dynamic Impedance: Provides stable reverse breakdown voltage necessary for accurate reference voltage under load conditions.
• Wide Operating Current Range: Capable of operating from 45µA to 15mA, making it versatile for diverse applications.
• High Stability: Over temperature and time, the output voltage remains consistent, which is crucial for precision applications.
• Compact Package: Available in the small SOT-23 package, which is ideal for space-constrained applications.

Applications

The LM4040C30FTA is suitable for a variety of applications, including:

• Portable and battery-powered electronics
• Power supply control and monitoring
• Data acquisition systems
• Analog-to-Digital (A/D) and Digital-to-Analog (D/A) converters
• Voltage monitoring

Performance and Reliability

Diodes Incorporated ensures that the LM4040C30FTA meets high-quality standards for performance and reliability. The device's precision voltage reference is designed to maintain stability across operational variations such as temperature fluctuations and load changes. This makes it a reliable component for critical and high-precision electronic systems.

Environmental and Regulatory Compliance

The LM4040C30FTA adheres to environmental standards, including RoHS compliance, which restricts the use of certain hazardous substances in electronic equipment. This commitment to environmental responsibility ensures that the product is suitable for use in a wide range of markets and applications that demand environmentally safe components.

With its robust design, precise voltage reference, and compliance with environmental standards, the LM4040C30FTA from Diodes Incorporated stands out as a reliable and efficient solution for precision voltage reference needs.
