Diodes Incorporated DPS1135FIA-13 Product Overview

The DPS1135FIA-13 is a high-performance, integrated power switch designed and manufactured by Diodes Incorporated, a leading global manufacturer and supplier of high-quality semiconductor products. This device is specifically engineered to provide a reliable power management solution for USB and other hot-swap applications.

Constructed with advanced technology, the DPS1135FIA-13 is a single channel, high-side load switch that offers a multitude of features to enhance system performance and safety. It is capable of delivering up to 2A of continuous current, making it suitable for a wide range of applications, including consumer electronics, portable devices, and industrial systems.

Key Features:

• Integrated Load Switch: The DPS1135FIA-13 integrates a P-channel MOSFET that can handle a continuous output current of up to 2A, providing an efficient means of controlling power distribution.
• Wide Input Voltage Range: This device supports an input voltage range of 1.5V to 5.5V, accommodating various power supply requirements and ensuring compatibility with low-voltage systems.
• Low On-Resistance: The low on-resistance of the MOSFET (typically 92mΩ) minimizes power loss and heat generation, contributing to the overall efficiency of the system.
• Fast Transient Response: With its quick response time, the DPS1135FIA-13 can effectively manage dynamic load variations, ensuring stable operation.
• Over-Current and Thermal Protection: The device includes built-in over-current and thermal shutdown features to protect the system from potential damage caused by excessive current or overheating.
• Controlled Rise Time: The DPS1135FIA-13 offers a programmable rise time to reduce inrush current, which can be critical in sensitive applications.
• Under-Voltage Lockout (UVLO): The UVLO feature ensures that the switch remains off when the input voltage is below a certain threshold, preventing malfunction due to insufficient supply voltage.

The DPS1135FIA-13 is available in a compact, leadless DFN2020-6 (Type B) package, which is not only space-efficient but also offers excellent thermal performance. Its small form factor makes it an ideal choice for portable devices where space is at a premium.

With its robust feature set and Diodes Incorporated's commitment to quality, the DPS1135FIA-13 is a reliable and efficient solution for designers looking to improve power management in their next project.
