The AH285-YL-13, from Diodes Incorporated, is a high-performance Hall Effect latch designed for electronic commutation of brushless DC motor applications, position and speed sensing, and various other magnetic switching implementations. This versatile and efficient component is a key player in the automation and control sectors, offering precision and reliability in a compact package.

Key Features

• Operating Voltage Range: The device operates within a voltage range of 3.5V to 20V, making it suitable for a variety of power environments and ensuring compatibility with a broad range of other electronic components.
• High Sensitivity: With a finely tuned magnetic sensing capability, the AH285-YL-13 can detect and respond to weak magnetic fields, ensuring accurate operation in applications requiring high precision.
• Chopper-Stabilized Design: The inclusion of a chopper-stabilized amplifier minimizes the electrical offset and drift over temperature, which enhances the stability and accuracy of the sensor’s performance.
• Robust Output: The open-drain output of the AH285-YL-13 can sink up to 25mA, allowing direct driving of a coil in DC motor applications without the need for additional amplification.
• Temperature Range: It is designed to operate over a wide temperature range from -40°C to 125°C, ensuring reliability and performance even in extreme conditions.

Applications

The AH285-YL-13 is highly adaptable and can be used in various applications such as:

• Brushless DC motor control
• Speed and position sensing
• Rotary encoders
• Magnetic switch for consumer, commercial, and industrial products

Quality and Reliability

Diodes Incorporated is committed to delivering high-quality products. The AH285-YL-13 is no exception, with rigorous testing and quality control measures in place to ensure that each device meets the highest standards of performance and reliability. It is available in a small and low-profile SOT-23 package, which is ideal for space-constrained applications.

Ordering Information

The part number AH285-YL-13 indicates the product is provided in a "tape and reel" packaging format, suitable for automated assembly processes, and is shipped in quantities of 3000 units per reel.
