Product Overview: AH175-PL-A-A from Diodes Incorporated

The AH175-PL-A-A is a versatile and robust magnetic Hall Effect sensor designed and manufactured by Diodes Incorporated, a leading global provider of high-quality semiconductor products. This sensor is part of the AH175 series, which are known for their reliability and effectiveness in detecting magnetic fields with precision.

Key Features

• High Sensitivity: The AH175-PL-A-A offers excellent sensitivity, making it capable of detecting even weak magnetic fields, which is essential for precise measurements and control.
• Polarity Detection: This sensor can detect both north and south pole magnetic fields, providing versatile applications in various types of electronic devices.
• Chopper-Stabilized Design: The chopper-stabilized amplifier design ensures stable operation over a wide temperature range and minimizes the effect of thermal and mechanical stresses on the sensor output.
• Open-Drain Output: The open-drain output of the AH175-PL-A-A allows for easy interface with other circuit components and provides the flexibility to connect multiple sensors in parallel.
• Wide Supply Voltage Range: This sensor operates over a broad supply voltage range from 3.5V to 20V, accommodating various application requirements and ensuring compatibility with different system designs.

Applications

The AH175-PL-A-A is suited for a wide array of applications, including but not limited to:

• Position and speed sensing in motors and industrial equipment
• Proximity detection in consumer electronics and smart devices
• Flow meters in water and gas utility systems
• Rotation detection in automotive systems
• Contactless switches and encoders in various control systems

Product Specifications

With its small form factor and low power consumption, the AH175-PL-A-A is a highly efficient sensor suitable for compact designs. The package type is SIP-3L, making it easy to integrate into various PCB layouts. Its operating temperature range from -40°C to 85°C ensures reliable performance under extreme environmental conditions.

The AH175-PL-A-A from Diodes Incorporated represents a blend of performance, reliability, and versatility, making it an excellent choice for designers and engineers looking to incorporate magnetic sensing capabilities into their projects.
