S25FL256SAGMFIR01 Real Image S25FL256SAGMFIR01 real image14980
Same model may have multiple batches, images only for reference.
S25FL256SAGMFIR01 Real Image S25FL256SAGMFIR01 real image14980
S25FL256SAGMFIR01 Real Image S25FL256SAGMFIR01 real image14980
Same model may have multiple batches, images only for reference.

S25FL256SAGMFIR01

Part No S25FL256SAGMFIR01
Manufacturer Cypress Semiconductor Corp
Catalog Flash
Description IC FLASH 256MBIT 133MHZ 16SOIC / NOR Flash Serial (SPI, Dual SPI, Quad SPI) 3V/3.3V 256M-bit 256M/128M/64M x 1/2-bit/4-bit 14.5ns 16-Pin SOIC W Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Cypress Semiconductor Corp
Series FL-S
Packaging Tube
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 256Mb (32M x 8)
Clock Frequency 133MHz
Memory Interface SPI - Quad I/O
Operating Supply Voltage 2.7 V ~ 3.6 V
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 16-SOIC (0.295", 7.50mm Width)
Manufacturer Package 16-SO
Win Source Part Number 793554-S25FL256SAGMFIR01
Popularity Medium
Supply and Demand Status Limited
Quantity per package 47
Family Name S25FL256S
Introduction Date May 25, 2011
ECCN 3A991.b.1.a
Country of Origin China, MalaysiaPhilippines, Taiwan, Thailand, United States of America
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian S25FL256SAGMFIR01 CAD Model

Description

The Cypress Semiconductor Corp electronic component is a part of the FL-S series with medium popularity and limited supply and demand status.

  • Win Source Part Number: 793554-S25FL256SAGMFIR01
  • Package: 16-SOIC (0.295", 7.50mm Width)
  • Memory Size: 256Mb (32M x 8)
  • Memory Format: FLASH
  • Clock Frequency: 133MHz
  • Memory Interface: SPI - Quad I/O
  • Operating Supply Voltage: 2.7 V ~ 3.6 V
  • Features: Halogen-free
  • EOL Date: 2027 (estimated)
