Same model may have multiple batches, images only for reference.

PDS1-S12-S5-S

Name: PDS1-S12-S5-S
Brand: CUI Inc.
SKU: 848144
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	PDS1-S12-S5-S
Manufacturer	CUI Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V 1W
Datasheet	PDS1-S12-S5-S Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	CUI Inc.
Series	PDS1-S (1W)
Package	Tube
Product Status	Active
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	10.8V
Voltage - Input (Max)	13.2V
Voltage - Output 1	5V
Current - Output (Max)	200mA
Power (Watts)	1 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	SCP
Temperature Range - Operating	-40°C ~ 105°C (With Derating)
Efficiency	80%
Mounting Type	Through Hole
Package / Case	4-SIP Module
Size / Dimension	0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm)
Approval Agency	CB Scheme, EN, IEC, UL
Standard Number	55024; 55032 Class A; 60950-1
Base Product Number	PDS1-S12
Standard Package	43 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	848144-PDS1-S12-S5-S
Ultra Librarian 3D Model	Ultra Librarian PDS1-S12-S5-S CAD Model

Alternative Products

Description

The 848144-PDS1-S12-S5-S is a 1W isolated module DC-DC converter from the PDS1-S series.

Application: Power supply applications in commercial ITE (Information Technology Equipment) devices
Power Rating: 1W
Protection: SCP (Short Circuit Protection)
Input Voltage Range: 10.8V to 13.2V
Maximum Output Voltage: 5V
Output Current: 200mA
Efficiency: 80%
Mounting Type: Through Hole
Package: 4-SIP Module
Operating Temperature: -40°C to 105°C (with derating)
Manufacturer: CUI Inc.
Product Status: Active
Standards Compliance: CB Scheme, EN, IEC, UL
