Same model may have multiple batches, images only for reference.

PQQ10W-Q24-S12-S

Name: PQQ10W-Q24-S12-S
Brand: CUI Inc.
SKU: 1340137
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	PQQ10W-Q24-S12-S
Manufacturer	CUI Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC-DC ISOLATED, 10 W, 9~36 VDC I / Isolated Module DC DC Converter 1 Output 12V 833mA 9V - 36V Input
Datasheet	PQQ10W-Q24-S12-S Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	CUI Inc.
Series	PQQ10W-S (10W)
Package	Tube
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	9V
Voltage - Input (Max)	36V
Voltage - Output 1	12V
Current - Output (Max)	833mA
Power (Watts)	10 W
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	88%
Mounting Type	Through Hole
Package / Case	8-SIP Module, 7 Leads
Size / Dimension	0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
Approval Agency	CE
Base Product Number	PQQ10W
Standard Package	22
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	1340137-PQQ10W-Q24-S12-S
Ultra Librarian 3D Model	Ultra Librarian PQQ10W-Q24-S12-S CAD Model

Alternative Products

Description

The PQQ10W-S (10W) series is an isolated module type DC-DC converter manufactured by CUI Inc. The 1340137-PQQ10W-Q24-S12-S is a part of this series and is a through-hole mounting type converter.

Power: 10W
Current Output: 833mA
Voltage Input: 9V to 36V
Voltage Output: 12V
Features: Remote On/Off
Efficiency: 88%
Application: ITE (Commercial)
Standard Package: 22
Package: Tube
Mounting Type: Through Hole
