The K78U05-500 is a non-isolated DC-DC converter manufactured by Crystek Corporation. It is designed as a high-efficiency replacement for linear regulators. This compact module provides a regulated 5V output voltage from a wider input voltage range, making it suitable for a variety of applications.

Applications

• Powering microcontrollers
• Replacing linear regulators
• Portable electronic devices
• Industrial control systems
• Battery-powered equipment

Features

• High efficiency (up to 95%)
• Non-isolated DC-DC converter
• Wide input voltage range
• Fixed 5V output voltage
• Short circuit protection
• Over-temperature protection
• Compact size
• Low ripple and noise

Benefits

• Energy savings due to high efficiency
• Reduced heat dissipation
• Longer battery life in portable devices
• Stable and reliable output voltage
• Simplified design

Additional Details

The K78U05-500 utilizes a switching regulator topology to achieve high efficiency. It offers protection against short circuits and over-temperature conditions, ensuring reliable operation. It is designed for easy integration into existing systems. The output current is 500mA.
