CLX6A-FKB-CJNNRFJBB7A363 Cree Inc.
Same model may have multiple batches, images only for reference.

CLX6A-FKB-CJNNRFJBB7A363

Part No CLX6A-FKB-CJNNRFJBB7A363
Manufacturer CreeLED, Inc.
Catalog LED Indication - Discrete
Description LED RGB DIFFUSED 6PLCC SMD
Datasheet
CLX6A-FKB-CJNNRFJBB7A363 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - LED Indication - Discrete
Mfr CreeLED, Inc.
Package Tape & Reel
Product Status Obsolete
Color Red, Green, Blue (RGB)
Configuration Independent
Lens Color White
Lens Transparency Diffused
Millicandela Rating 785mcd Red, 1570mcd Green, 392mcd Blue
Lens Style Square with Flat Top
Lens Size 1.00mm
Voltage - Forward (Vf) (Typ) 2V Red, 3.2V Green, 3.2V Blue
Current - Test 20mA Red, 20mA Green, 20mA Blue
Mounting Type Surface Mount
Wavelength - Dominant 622nm Red, 530nm Green, 470nm Blue
Package / Case 6-SMD, J-Lead
Supplier Device Package 6-PLCC
Size / Dimension 3.50mm L x 3.40mm W
Height (Max) 2.90mm
Base Product Number CLX6A
Standard Package 2,800 pcs
Moisture Sensitivity Level (MSL) 5A (24 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 579248-CLX6A-FKB-CJNNRFJBB7A363
Ultra Librarian 3D Model Ultra Librarian CLX6A-FKB-CJNNRFJBB7A363 CAD Model

Description

The 579248-CLX6A-FKB-CJNNRFJBB7A363 is a versatile LED indication component in the Optoelectronics category.

  • Mounting: Surface mount
  • Package: 6-SMD, J-Lead
  • Lens Style: Square
  • Lens: Flat top
  • Lens Color: White
  • Lens Transparency: Diffused
  • LED Colors: Red, Green, and Blue (RGB)
  • Red LED Milli-Candela: 785mcd
  • Red LED Voltage Forward: 2V
  • Red LED Current Test: 20mA
  • Green LED Milli-Candela: 1570mcd
  • Green LED Voltage Forward: 3.2V
  • Green LED Current Test: 20mA
  • Blue LED Milli-Candela: 392mcd
  • Blue LED Voltage Forward: 3.2V
  • Blue LED Current Test: 20mA
  • Standard Package: 2,800 pcs
