C3D16060D Cree Inc.
Same model may have multiple batches, images only for reference.

C3D16060D

Part No C3D16060D
Manufacturer Cree/Wolfspeed
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 600V TO247
Datasheet
C3D16060D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Cree/Wolfspeed
Series Z-Rec®
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology SiC (Silicon Carbide) Schottky
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) (per Diode) 8A (DC)
Voltage - Forward (Vf) (Max) @ If 1.8 V @ 8 A
Speed No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) 0 ns
Current - Reverse Leakage @ Vr 50 µA @ 600 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case TO-247-3
Supplier Device Package TO-247-3
Base Product Number C3D16060
Standard Package 30 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 575797-C3D16060D
Ultra Librarian 3D Model Ultra Librarian C3D16060D CAD Model

Description

The C3D16060D is a high-performance diode array designed for rectification applications. Manufactured by Cree/Wolfspeed, it is a reliable choice for your rectification needs.

  • Series: Z-Rec®
  • Technology: SiC (Silicon Carbide) Schottky
  • Voltage Rating: 600V
  • Current Rating: 8A
  • Recovery Time: No recovery time
  • Mounting: Through-Hole
  • Temperature Range: -55°C to 175°C
  • Configuration: Common Cathode
  • Standard Package: 30 pcs
