XPCWHT-L1-0000-00901 Real Image
Same model may have multiple batches, images only for reference.

XPCWHT-L1-0000-00901

Part No XPCWHT-L1-0000-00901
Manufacturer Cree Inc.
Catalog LED Lighting - White
Description LED XLAMP COOL WHITE 70CRI 2SMD
Datasheet
XPCWHT-L1-0000-00901 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Optoelectronics
Manufacturer Cree Inc.
Packaging Reel - TR
Status Active
Color White, Cool
CCT (K) 5000K to 10000K
Flux @ 25°C, Current - Test 84 lm (81 lm to 87 lm)
Current - Test 350mA
Forward Voltage 3.2V
Lumens/Watt @ Current - Test 75 lm/W
CRI (Color Rendering Index) 70 (Typ)
Current - Max 500mA
Viewing Angle 115°
Mounting SMD (SMT)
Height - Seated (Max) 0.084" (2.13mm)
Thermal Resistance of Package 12°C/W
Win Source Part Number 214586-XPCWHT-L1-0000-00901
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian XPCWHT-L1-0000-00901 CAD Model

Description

The Cree Inc. XPCWHT-L1-0000-00901 is a surface-mount white LED that emits a cool white light.

  • Height: It has a maximum seated height of 0.084 inches.
  • Viewing Angle: and a viewing angle of 115 degrees.
  • Maximum Current: The LED has a maximum current of 500mA.
  • Forward Voltage: and a forward voltage of 3.2V.
  • CCT: The CCT ranges from 5000K to 10000K.
  • CRI: and the CRI is 70 (typical).
  • Thermal Resistance: The thermal resistance of the package is 12 degrees Celsius per watt.
  • Flux: The LED has a flux of 84 lumens @ 25 degrees Celsius and a current of 350mA.
  • Lumens-to-Watt Ratio: with a lumens-to-watt ratio of 75 lm/W.
  • Suitability: This LED is suitable for use in optoelectronics applications.
