Same model may have multiple batches, images only for reference.
MGS301205-R Real Image
Same model may have multiple batches, images only for reference.

MGS301205-R

Part No MGS301205-R
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V 30W / Isolated Module DC DC Converter 1 Output 5V 6A 9V - 18V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Cosel USA, Inc.
Series MGS (30W)
Package Box
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 9V
Voltage - Input (Max) 18V
Voltage - Output 1 5V
Current - Output (Max) 6A
Power (Watts) 30 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 91%
Mounting Type Through Hole
Package / Case 6-DIP Module
Size / Dimension 2.00" L x 1.00" W x 0.39" H (50.8mm x 25.4mm x 9.9mm)
Base Product Number MGS301205
Standard Package 1
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1348968-MGS301205-R
Ultra Librarian 3D Model Ultra Librarian MGS301205-R CAD Model

Description

The Cosel MGS301205-R is an isolated module DC-DC converter that is designed for ITE (commercial) applications.

  • Application: ITE (Commercial)
  • Voltage Input: 9-18V
  • Voltage Isolation: 1.5 kV
  • Output: Single
  • Voltage Output: 5V
  • Current Output: 6A
  • Efficiency: 91%
  • Mounting Type: Through-Hole
  • Temperature Range: -40°C to 85°C (with derating)
