MGFW102412 Real Image
Same model may have multiple batches, images only for reference.

MGFW102412

Part No MGFW102412
Manufacturer Cosel USA, Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-12V 10W / Isolated Module DC DC Converter 2 Output 12V -12V 420mA, 420mA 9V - 36V Input
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Cosel USA, Inc.
Series MGFW (10W)
Package Tube
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 420mA, 420mA
Power (Watts) 10 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 87%
Mounting Type Through Hole
Package / Case 7-SIP Module
Size / Dimension 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
Standard Package 1
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
California Prop 65 Warning Information
Win Source Part Number 1338607-MGFW102412
Ultra Librarian 3D Model Ultra Librarian MGFW102412 CAD Model

Description

The Cosel USA MGFW102412 is a 10W isolated module DC-DC converter designed for power supplies board mount applications.

  • Package Type: Tube
  • Mounting Type: Through-Hole
  • Application: ITE (Commercial)
  • Features: Remote On/Off, OCP
  • Standard Package: 1
  • Maximum Current Output: 420mA
  • Input Voltage: 9V
  • Output Voltage: 12V/-12V
  • Dimension: 0.87 inches in length, 0.37 inches in width, and 0.47 inches in height
  • Efficiency: 87%
  • Voltage Isolation: 1.5 kV
  • ECCN: EAR99
  • MSL Level: 1 (Unlimited)
  • HTSUS: 8504.40.9580
  • Supplier Device Package: Not Specified
