Same model may have multiple batches, images only for reference.
SPA680M06R Real Image
Same model may have multiple batches, images only for reference.

SPA680M06R

Part No SPA680M06R
Manufacturer Cornell Dubilier Electronics (CDE)
Catalog Aluminum - Polymer Capacitors
Datasheet
SPA680M06R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum - Polymer Capacitors
Mfr Cornell Dubilier Electronics (CDE)
Series SPA
Package Tape & Reel (TR)
Product Status Obsolete
Type Polymer
Capacitance 68 µF
Tolerance ±20%
Voltage - Rated 6.3 V
ESR (Equivalent Series Resistance) 9mOhm
Lifetime @ Temp. 1000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Applications General Purpose
Ripple Current @ High Frequency 3 A @ 100 kHz
Dimension 0.287" L x 0.169" W (7.30mm x 4.30mm)
Height - Seated (Max) 0.075" (1.90mm)
Surface Mount Land Size 0.287" L x 0.169" W (7.30mm x 4.30mm)
Mounting SMD (SMT)
Package / Case 2917 (7343 Metric)
Standard Package 3,500
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1308467-SPA680M06R
Ultra Librarian 3D Model Ultra Librarian SPA680M06R CAD Model

Description

The SPA680M06R is a polymer type aluminum capacitor with a capacitance of 68µF and a voltage rating of 6.3V. It has an equivalent series resistance of 9mOhm and is designed for general purpose applications. This capacitor is manufactured by Cornell Dubilier Electronics (CDE) and is categorized under Capacitors>Aluminum - Polymer Capacitors. It has a package type of 2917 (7343 Metric) and is surface mountable. It is obsolete and has a ripple current of 3A at 100 kHz.
