SLP682M035E1P3

Get a Quote

Part No	SLP682M035E1P3
Manufacturer	Cornell Dubilier Electronics (CDE)
Catalog	Aluminum Capacitors
Datasheet	SLP682M035E1P3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Aluminum Electrolytic Capacitors
Mfr	Cornell Dubilier Electronics (CDE)
Series	SLP0712TE (750W)
Package	Bulk
Capacitance	6800 µF
Tolerance	±20%
Voltage - Rated	35 V
ESR (Equivalent Series Resistance)	78mOhm @ 120Hz
Lifetime @ Temp.	3000 Hrs @ 105°C
Temperature Range - Operating	-40°C ~ 105°C
Polarization	Polar
Applications	General Purpose
Ripple Current @ Low Frequency	2.78 A @ 120 Hz
Ripple Current @ High Frequency	3.48 A @ 20 kHz
Lead Spacing	0.394" (10.00mm)
Dimension	1.181" Dia (30.00mm)
Height - Seated (Max)	0.984" (25.00mm)
Mounting Type	Through Hole
Package / Case	Radial, Can - Snap-In
Standard Package	50
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0040
Win Source Part Number	1307845-SLP682M035E1P3
Ultra Librarian 3D Model	Ultra Librarian SLP682M035E1P3 CAD Model

Description

The Cornell Dubilier Electronics (CDE) SLP0712TE (750W) series aluminum electrolytic capacitor is a high-quality component that can be used for general purpose applications.

Application: General purpose
Capacitance: 6800 µF
Voltage Rating: 35 V
Tolerance: ±20%
ESR (Equivalent Series Resistance): 78mOhm @ 120Hz
Lifetime: 3000 Hrs @ 105°C
Polarized: Yes
Mounting Type: Through-hole
Package/Case: Radial, can-snap-in
Dimension: 1.181" Dia (30.00mm)
