SLP103M010A1P3

Part No SLP103M010A1P3
Manufacturer Cornell Dubilier Electronics (CDE)
Catalog Aluminum Capacitors
Description CAP ALUM 10000UF 20% 10V SNAP / 10000 µF 10 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 73mOhm @ 120Hz 3000 Hrs @ 105°C
Datasheet
SLP103M010A1P3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr Cornell Dubilier Electronics (CDE)
Series SLP0712TE (750W)
Package Bulk
Capacitance 10000 µF
Tolerance ±20%
Voltage - Rated 10 V
ESR (Equivalent Series Resistance) 73mOhm @ 120Hz
Lifetime @ Temp. 3000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 1.8 A @ 120 Hz
Ripple Current @ High Frequency 2.25 A @ 20 kHz
Lead Spacing 0.394" (10.00mm)
Dimension 0.866" Dia (22.00mm)
Height - Seated (Max) 0.984" (25.00mm)
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0040
Standard Package 100
Win Source Part Number 1222315-SLP103M010A1P3
Ultra Librarian 3D Model Ultra Librarian SLP103M010A1P3 CAD Model

Description

The Cornell Dubilier Electronics (CDE) 1222315-SLP103M010A1P3 is a bulk aluminum electrolytic capacitor with a capacitance of 10000 µF and a voltage rating of 10 V.

  • Capacitance: 10000 µF
  • Voltage Rating: 10 V
  • Tolerance: ±20%
  • ESR: 73mOhm @ 120Hz
  • Package: Radial, can - snap-in
  • Lead Spacing: 0.394" (10.00mm)
  • Height: 0.984" (25.00mm)
  • Diameter: 0.866" (22.00mm)
  • Application: General-purpose
  • Lifetime: 3000 Hrs @ 105°C
  • Temperature Range: -40°C ~ 105°C
  • Polarity: Polar
  • Mounting: Through hole
