DR1030-220-R Real Image
Same model may have multiple batches, images only for reference.

DR1030-220-R

Part No DR1030-220-R
Manufacturer Cooper Bussmann, Inc.
Catalog Fixed Inductors
Description FIXED IND 22UH 1.8A 114.6 MOHM / Shielded power inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Eaton - Electronics Division
Packaging Reel
Type Wirewound
Material - Core Ferrite
Inductance 22μH
Tolerance ±30%
Current Rating (Amps) 1.8A
Current - Saturation 2.19A
Shielding Shielded
DC Resistance (DCR) 114.6mOhm Max
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100kHz
Mounting Style SMD
Manufacturer Package Nonstandard
Dimension 0.413" L x 0.406" W (10.50mm x 10.30mm)
Height - Seated (Maximum) 0.118" (3.00mm)
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 808444-DR1030-220-R
Ultra Librarian 3D Model Ultra Librarian DR1030-220-R CAD Model

Description

The Eaton 808444-DR1030-220-R is a shielded wirewound inductor designed for use in electronic circuits.

  • Inductance: 22μH
  • Current Rating: 1.8A
  • DC Resistance: 114.6mOhm maximum
  • Tolerance: ±30%
  • Material: Ferrite
  • Saturation Current: 2.19A
  • Temperature Range: -40°C to 125°C
  • Manufacturer Pack Quantity: 1,000
  • Dimension: 0.413" L x 0.406" W (10.50mm x 10.30mm)
  • Height: 0.118" (3.00mm)
