MSS1048-184KLB Real Image
Same model may have multiple batches, images only for reference.

MSS1048-184KLB

Part No MSS1048-184KLB
Manufacturer Coilcraft
Catalog Fixed Inductors
Description Power inductor, shielded, 10/20/30% tol, SMT, RoHS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Core Material Ferrite
DC Resistance (DCR) 356.5 mΩ
Height 5.1 mm
Inductance 180 µH
Inductance Tolerance 10 %
Lead Free Contains Lead
Length 10.5 mm
Max DC Current 1.24 A
Maximum Operating Temperature 85 °C
Min Operating Temperature -40 °C
Packaging Cut Tape
REACH SVHC No SVHC
RMS Current (Irms) 1.24 A
RoHS Compliant
Saturation Current 750 mA
Self Resonant Frequency 4.5 MHz
Shielding Shielded
Termination SMD/SMT
Test Frequency 100 kHz
Tolerance 10 %
Width 10.3 mm
Win Source Part Number 1003539-MSS1048-184KLB
Categories Fixed Inductors
Manufacturer Coilcraft
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian MSS1048-184KLB CAD Model

Description

The Coilcraft MSS1048-184KLB is a fixed inductor with a 180 µH inductance and a 10% tolerance.

  • Manufacturer:Coilcraft
  • Inductance: 180 µH
  • Tolerance: 10%
  • Core Material: Ferrite
  • Shielded: Yes
  • Self-Resonant Frequency: 4.5 MHz
  • RoHS Compliant: Yes
  • Popularity: Low
  • Supply and Demand: Shortage
  • Maximum DC Current: 1.24 A
  • DC Resistance: 356.5 mΩ
