The WM8782SEDS/RV is a high-performance, low-power stereo audio codec designed by Cirrus Logic. It integrates analog-to-digital converters (ADCs) and digital-to-analog converters (DACs) to provide a complete audio solution for portable and embedded applications where audio quality and power efficiency are critical.

Applications:

• Portable audio recorders
• Mixing consoles
• Audio interfaces
• Effects processors
• Home audio equipment

Features:

• Stereo ADC and DAC
• Low power consumption
• Integrated microphone preamplifier
• Line-level inputs and outputs
• Digital volume control
• I2S digital audio interface
• Flexible clocking options

Benefits:

• Superior Audio Quality: Delivers excellent audio performance for both recording and playback.
• Integrated Solution: Combines ADC and DAC functions into a single chip, simplifying system design and reducing component count.
• Energy Efficient: Low power consumption maximizes battery life in portable devices.
• Versatile Connectivity: Supports various audio input and output options, offering flexibility in system design.
• Precise Level Control: Provides accurate and repeatable level adjustments through digital volume control.

The WM8782SEDS/RV incorporates high-performance ADCs and DACs, supporting sample rates up to 96 kHz for high-fidelity audio capture and reproduction. The integrated microphone preamplifier simplifies the design of recording systems by allowing direct connection of microphones. The line-level inputs and outputs offer compatibility with a wide range of audio equipment. Digital volume control enables precise level adjustments without introducing noise or distortion. The I2S digital audio interface facilitates seamless integration with other digital audio components. The flexible clocking options provide versatility in system configuration.

Specifications:

• Channels: Stereo
• ADC Resolution: 24-bit
• DAC Resolution: 24-bit
• Sample Rate: Up to 96 kHz
• Interface: I2S
• Power Consumption: Low
