Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Bulk
Status Obsolete
Transistor Type PNP - Darlington
Current - Collector (Ic) (Maximum) 8A
Voltage - Collector Emitter Breakdown (Maximum) 80V
Vce Saturation (Maximum) at Ib, Ic 2.5V at 80mA, 8A
Current - Collector Cutoff (Maximum) 50μA
DC Current Gain (hFE) (Minimum) at Ic, Vce 1000 at 3A, 4V
Maximum Power 80W
Frequency - Transition 4MHz
Temperature Range - Operating -65°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package TO-220-3
Supplier Device Package TO-220
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Win Source Part Number 1267396-TIP106
Manufacturer Homepage www.mospec.com.tw
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TIP106 CAD Model

Description

The TIP106 is a PNP Darlington transistor from Central Semiconductor Corp.

  • Collector Current (Max): 8A
  • Collector-Emitter Breakdown Voltage: 80V
  • Applications: High voltage and high current applications such as power supplies and motor control circuits
  • Package: TO-220
  • Supply and Demand: Limited
  • DC current gain (hFE): 1000 @ 3A, 4V
  • Maximum Power: 80W
