Products specifications

Manufacturer Central Semiconductor Corp
Win Source Part Number 1162320-CMKD7000
Manufacturer Homepage www.centralsemi.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management, Safety
Ultra Librarian 3D Model Ultra Librarian CMKD7000 CAD Model

Description

The CMKD7000 is a diode array manufactured by Central Semiconductor Corp. It's designed to provide a compact solution for applications requiring multiple diodes in a single package. The CMKD7000 is comprised of two high-speed switching diodes in a common cathode configuration.

Applications

  • High-speed switching circuits
  • Protection circuits
  • Voltage clamping
  • Data line protection
  • Small signal rectification

Features

  • Two high-speed switching diodes in one package
  • Common cathode configuration
  • Low capacitance
  • Fast switching speed
  • Surface mount package

Benefits

  • Reduces board space by integrating two diodes into one package
  • Improves switching performance due to low capacitance and fast switching speed
  • Simplifies circuit design
  • Enhances reliability

Additional Details

The CMKD7000 typically comes in a SOT-363 package. Key specifications include a repetitive peak reverse voltage (VRRM) of 100V, a forward current (IF) of 200mA, and a reverse recovery time (trr) of approximately 4ns. Its low capacitance ensures minimal impact on high-frequency signals. The device is designed to operate within a temperature range of -65°C to +150°C. Because of its low profile and small footprint, the CMKD7000 is ideal for use in densely populated circuit boards and portable electronic devices. It offers excellent performance characteristics for high-speed applications. These arrays are often used in applications where transient voltage suppression is required. The common cathode configuration simplifies certain circuit designs. The device’s robustness and electrical characteristics make it a reliable component in various electronic systems.
