Same model may have multiple batches, images only for reference.

MGA-30116-TR1G

Name: MGA-30116-TR1G
Brand: Broadcom Limited
SKU: 639142
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MGA-30116-TR1G
Manufacturer	Broadcom Limited
Catalog	RF Amplifiers
Description	150MHz – 1GHz 1/2 Watt High Linearity Amplifier Standard QFN 3X3 package \| IC RF AMP CDMA 400MHZ-1GHZ 16QFN
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	RF/IF and RFID
Manufacturer	Broadcom Limited
Packaging	Tape and Reel
Status	Obsolete
Frequency	400MHz ~ 1GHz
P1dB	27.7dBm
Gain	17dB
Noise Figure	2dB
RF Type	CDMA, GSM
Supply Voltage (V)	5V
Supply Current	400mA
Test Frequency	900MHz
Manufacturer Package	16-VFQFN Exposed Pad
Supplier Device Package	16-QFN (3x3)
Manufacturer Pack Quantity	1,000
MSL Level	1 (Unlimited)
Win Source Part Number	1221830-MGA-30116-TR1G
Manufacturer Homepage	www.avagotech.com
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	MGA-30116
Introduction Date	January 01, 2008
ECCN	5A991.g
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	Obsolete
Ultra Librarian 3D Model	Ultra Librarian MGA-30116-TR1G CAD Model

Description

The MGA-30116-TR1G is a low-noise amplifier designed for use in CDMA and GSM applications and is manufactured by Broadcom Limited.

Gain: 17dB with a test frequency of 900MHz
Supply Current: 400mA
Noise Figure: 2dB
P1dB: 27.7dBm
Package: 16-QFN (3x3)
Status: obsolete part
Alternative Part: ADL5542ACPZ-R7 with a high popularity in the market
