HEDS-9780#G54 real image HEDS-9780#G54 label picture
Same model may have multiple batches, images only for reference.
HEDS-9780#G54 real image HEDS-9780#G54 label picture
HEDS-9780#G54 real image HEDS-9780#G54 label picture
Same model may have multiple batches, images only for reference.

HEDS-9780#G54

Part No HEDS-9780#G54
Manufacturer Broadcom Limited
Catalog Encoders
Description ENCODER SMALL 2CH 360CPR 80KHZ
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Broadcom Limited
Status Active
Encoder Type Optical
Output Type Quadrature (Incremental)
Pulses per Revolution 360
Supply Voltage - Operating 5V
Actuator Type Codewheel Not Included
Detent No
Built in Switch No
Mounting Chassis Mount
Termination Style Terminal Pins
Win Source Part Number 118237-HEDS-9780#G54
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HEDS-9780#G54 CAD Model

Description

The Broadcom Limited HEDS-9780#G54 is an optical encoder.

  • Output Type: Quadrature
  • Pulses per Revolution: 360
  • Mounting: Chassis mount
  • Termination Style: Terminal pins
  • Codewheel: Not included
  • Switch: No built-in switch
  • Application: Sensors and transducers
  • Operating Supply Voltage: 5V
  • Package Quantity: 50
