Same model may have multiple batches, images only for reference.

HCPL-817-56BE

Name: HCPL-817-56BE
Brand: Broadcom Limited
SKU: 142124
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-817-56BE
Manufacturer	Broadcom Limited
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISOLATOR 5KV TRANSISTOR 4SMD
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Number of Channels	1
Isolation Voltage	5000Vrms
Minimum DC Current Transfer Ratio	130% @ 5mA
Maximum DC Current Transfer Ratio	260% @ 5mA
Rise and Fall Time	4μs, 3μs
Input Type	DC
Output Type	Transistor
Maximum Output Voltage	70V
Channel Output Current	50mA
Forward Voltage	1.2V
Continuous forward current- Max	50mA
Vce Saturation (Max)	200mV
Temperature Range - Operating	-30°C to 100°C
Mounting	SMD (SMT)
Case / Package	4-SMD
Win Source Part Number	067936-HCPL-817-56BE
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	HCPL-817
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Singapore, Thailand
Halogen Free	Not Compliant
Estimated EOL Date	2023
Quantity per package	1k pcs
Ultra Librarian 3D Model	Ultra Librarian HCPL-817-56BE CAD Model

Alternative Products

Description

The HCPL-817-56BE is a high-performance optocoupler from Broadcom Limited. It is designed to provide high isolation voltage and excellent current transfer ratio.

Channels: 1
Output Type: Transistor
Forward Voltage: 1.2V
Vce Saturation (Max): 200mV
Isolation Voltage: 5000Vrms
Minimum DC Current Transfer Ratio: 130% @ 5mA
Maximum DC Current Transfer Ratio: 260% @ 5mA
Rise Time: 4μs
Fall Time: 3μs
Package: 4-SMD
Operating Temperature: -30°C to 100°C
