HCPL-7800 Real Image HCPL-7800 real image4569
Same model may have multiple batches, images only for reference.
HCPL-7800 Real Image HCPL-7800 real image4569
HCPL-7800 Real Image HCPL-7800 real image4569
Same model may have multiple batches, images only for reference.

HCPL-7800

Part No HCPL-7800
Manufacturer Broadcom Limited
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP ISOLATION 100KHZ 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Amplifier Type Isolation
Number of Circuits 1
-3db Bandwidth 100kHz
Current - Input Bias 500nA
Voltage - Input Offset 300μV
Operating Supply Current 10.9mA
Channel Output Current 16mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 067924-HCPL-7800
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-7800 CAD Model

Description

The HCPL-7800 is an isolation amplifier manufactured by Broadcom Limited.

  • Channels: 1
  • -3db Bandwidth: 100kHz
  • Mounting: Through-Hole
  • Packaging: Tube/Rail
  • Input Bias Current: 500nA
  • Input Offset Voltage: 300μV
  • Status: Active
  • Operating Temperature: -40°C to 85°C
  • Supply Voltage: 4.5 V to 5.5 V
  • Operating Supply Current: 10.9mA
  • Channel Output Current: 16mA
  • Package: 8-DIP
