HCPL-6250 Broadcom Limited
Same model may have multiple batches, images only for reference.

HCPL-6250

Part No HCPL-6250
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 1.5KV PUSH PULL 16FLATPK / Logic Output Optoisolator 5MBd Push-Pull, Totem Pole 1500VDC 4 Channel 1kV/µs CMTI 16-FlatPack
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Logic Output Optoisolators
Mfr Broadcom Limited
Series -
Package Tube
Product Status Active
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Voltage - Isolation 1500VDC
Common Mode Transient Immunity (Min) 1kV/µs
Input Type DC
Output Type Push-Pull, Totem Pole
Current - Output / Channel 15 mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 350ns, 350ns
Rise / Fall Time (Typ) 45ns, 10ns
Voltage - Forward (Vf) (Typ) 1.3V
Current - DC Forward (If) (Max) 8mA
Voltage - Supply 4.5V ~ 20V
Temperature Range - Operating -55°C ~ 125°C
Mounting Type Surface Mount
Package / Case 16-FlatPack
Supplier Device Package 16-FlatPack
Base Product Number HCPL-6250
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 1355638-HCPL-6250
Ultra Librarian 3D Model Ultra Librarian HCPL-6250 CAD Model

Description

The HCPL-6250 is a logic output optoisolator component manufactured by Broadcom Limited.

  • Package: 16-FlatPack
  • Status: Active
  • Voltage Supply: 4.5V to 20V
  • Data Rate: 5MBd
  • Channels: Four
  • Current Output per Channel: 15mA
  • Voltage Isolation: 1500VDC
  • Output Type: Push-pull, totem pole
  • Forward Voltage: 1.3V @ 8mA (typical)
  • Mounting Type: Surface mount
