HCPL-6650 Real Image
Same model may have multiple batches, images only for reference.

HCPL-6650

Part No HCPL-6650
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 1.5KV OPEN COLL 16FLATPK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Isolation Voltage 1500VDC
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 25mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 35ns, 35ns
Forward Voltage 1.5V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 16-Flatpack
Win Source Part Number 040458-HCPL-6650
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1
Ultra Librarian 3D Model Ultra Librarian HCPL-6650 CAD Model

Description

The Broadcom Limited 040458-HCPL-6650 is a 4-channel optoisolator that is part of the optoisolators - transistor, photovoltaic output family.

  • Number of Channels: 4
  • Data Rate: 10MBd
  • Common Mode Transient Immunity: 1kV/μs
  • Packaging: 16-Flatpack
  • Popularity: Medium
