HCPL-3150-000E

Name: HCPL-3150-000E
Brand: Broadcom Limited
SKU: 457773
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-3150-000E
Manufacturer	Broadcom Limited
Catalog	Isolators - Gate Drivers
Description	OPTOISO 3.75KV GATE DRIVER 8DIP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Tube/Rail
Status	Active
Technology	Optical Coupling
Number of Channels	1
Isolation Voltage	3750Vrms
Common Mode Transient Immunity (Min)	15kV/μs
Propagation Delay tpLH / tpHL (Max)	500ns, 500ns
Pulse Width Distortion (Max)	300ns
Rise and Fall Time	100ns, 100ns
Current - Output High, Low	500mA, 500mA
Current - Peak Output	600mA
Forward Voltage	1.5V
Continuous forward current- Max	25mA
Supply Voltage - Operating	15 V to 30 V
Temperature Range - Operating	-40°C to 100°C
Mounting	Through Hole
Case / Package	8-DIP
Approvals	CSA, UR
Win Source Part Number	1042689-HCPL-3150-000E
Popularity	Medium
Supply and Demand Status	Balance
Quantity per package	50
Ultra Librarian 3D Model	Ultra Librarian HCPL-3150-000E CAD Model

Description

The Broadcom HCPL-3150-000E is an optical coupling device that has a common mode transient immunity of 15kV/μs.

Common Mode Transient Immunity: 15kV/μs
Package: 8-DIP
Mounting: Through Hole
Isolation Voltage: 3750Vrms
Approvals: CSA and UR
Operating Temperature: -40°C to 100°C
Supply Voltage Range: 15V to 30V
