HCPL-3120-000E Broadcom Limited HCPL-3120-000E Real Image HCPL-3120-000E Real Image HCPL-3120-000E label picture 3 HCPL-3120-000E label picture 4 HCPL-3120-000E real image
Same model may have multiple batches, images only for reference.
HCPL-3120-000E Broadcom Limited HCPL-3120-000E Real Image HCPL-3120-000E Real Image HCPL-3120-000E label picture 3 HCPL-3120-000E label picture 4 HCPL-3120-000E real image
HCPL-3120-000E Broadcom Limited HCPL-3120-000E Real Image HCPL-3120-000E Real Image HCPL-3120-000E label picture 3 HCPL-3120-000E label picture 4 HCPL-3120-000E real image
Same model may have multiple batches, images only for reference.

HCPL-3120-000E

Part No HCPL-3120-000E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 3.75KV GATE DRIVER 8DIP
Datasheet
HCPL-3120-000E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise and Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting Through Hole
Case / Package 8-DIP
Approvals CSA, UR
Win Source Part Number 089855-HCPL-3120-000E
Family Name HCPL-3120
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Philippines, Singapore, Thailand
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-3120-000E CAD Model

Description

The HCPL-3120-000E is an optical coupling technology-based isolator from Broadcom Limited. It is widely used in industrial applications and motor drive & control systems. The device has a high popularity and sufficient supply and demand status. The estimated EOL date is 2023.

  • Technology: Optical Coupling
  • Common Mode Transient Immunity: 25kV/μs
  • Isolation Voltage: 3750Vrms
  • Propagation Delay (Max): 500ns
  • Pulse Width Distortion: 300ns
  • Current Output (High/Low): 2A, 2A
  • Operating Temperature: -40°C to 100°C
  • Supply Voltage: 15 V to 30 V
  • Mounting: Through-Hole
  • Package: 8-DIP
