HCPL-2731-000E Real Image HCPL-2731-000E Real Image
Same model may have multiple batches, images only for reference.
HCPL-2731-000E Real Image HCPL-2731-000E Real Image
HCPL-2731-000E Real Image HCPL-2731-000E Real Image
Same model may have multiple batches, images only for reference.

HCPL-2731-000E

Part No HCPL-2731-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV 2CH DARLNG 8-DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 500% @ 1.6mA
Maximum DC Current Transfer Ratio 2600% @ 1.6mA
Switching Turn-On and Turn-Off Time 5μs, 10μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 18V
Channel Output Current 60mA
Forward Voltage 1.4V
Continuous forward current- Max 12mA
Vce Saturation (Max) 100mV
Temperature Range - Operating 0°C to 70°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 067904-HCPL-2731-000E
Popularity Medium
Supply and Demand Status Limited
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-2731-000E CAD Model

Description

The HCPL-2731-000E is a DC input darlington optocoupler, which is manufactured by Broadcom Limited.

  • Package: 8-DIP
  • Channels: 2
  • Minimum DC Current Transfer Ratio: 500% @ 1.6mA
  • Maximum DC Current Transfer Ratio: 2600% @ 1.6mA
  • Voltage Isolation: 3750Vrms
  • Maximum Output Voltage: 18V
  • Temperature Range: 0°C to 70°C
  • Turn On Time: 5μs
  • Turn Off Time: 10μs
  • Quantity per Package: 50
