HCPL-2630-000E

Part No HCPL-2630-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV 2CH OPEN COL 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.5V
Continuous forward current- Max 15mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 090063-HCPL-2630-000E
Family Name HCPL-2630
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Singapore, Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian HCPL-2630-000E CAD Model

Description

The Broadcom Limited 090063-HCPL-2630-000E is an Isolator with an Open Collector, Schottky Clamped output type. It has a data rate of 10MBd and a common mode transient immunity of 5kV/μs. The device has a propagation delay tpLH / tpHL of 100ns and 100ns respectively. It has an isolation voltage of 3750Vrms and comes in an 8-DIP package. The device can operate in a temperature range of -40°C to 85°C and requires a supply voltage of 4.5 V to 5.5 V. It has a rise and fall time of 24ns and 10ns respectively. The device has a channel output current of 50mA and a continuous forward current of 15mA. The device is popular in the market and has a balanced supply and demand status. The device is supplied in a package of 50.
