HCPL-181-00CE Real Image HCPL-181-00CE real image4557 HCPL-181-00CE real image4558
Same model may have multiple batches, images only for reference.
HCPL-181-00CE Real Image HCPL-181-00CE real image4557 HCPL-181-00CE real image4558
HCPL-181-00CE Real Image HCPL-181-00CE real image4557 HCPL-181-00CE real image4558
Same model may have multiple batches, images only for reference.

HCPL-181-00CE

Part No HCPL-181-00CE
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS 4MINIFLAT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 200% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Rise and Fall Time 4μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 200mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-Mini-Flat
Win Source Part Number 016853-HCPL-181-00CE
Family Name HCPL-181
Introduction Date November 01, 2004
ECCN EAR99
Country of Origin China, Singapore
Halogen Free Not Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Computers & Computer Peripherals, Test & Measurement
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL-181-00CE CAD Model

Description

The Broadcom Limited HCPL-181-00CE is a transistor output type isolator.

  • Isolation Voltage: 3750Vrms
  • DC Current Transfer Ratio: 200% (min) / 400% (max) @ 5mA
  • Switching Time: Unspecified
  • Rise/Fall Time: 4μs / 3μs
  • Mounting Type: SMD (SMT)
  • Package: 4-Mini-Flat
  • Applications: Computers/Peripherals, Test/Measurement
