HCPL-0721-500E

Name: HCPL-0721-500E
Brand: Broadcom Limited
SKU: 141875
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-0721-500E
Manufacturer	Broadcom Limited
Catalog	Optoisolators - Logic Output
Description	Optocoupler Logic-Out Push-Pull Logic, Buffer-IN 1-CH 8-Pin SOIC T/R / OPTOISO 3.75KV PUSH PULL 8SO
Datasheet	HCPL-0721-500E Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Broadcom Limited
Packaging	Reel - TR
Status	Active
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Isolation Voltage	3750Vrms
Common Mode Transient Immunity (Min)	10kV/μs
Input Type	Logic
Output Type	Push-Pull, Totem Pole
Channel Output Current	10mA
Data Rate	25MBd
Propagation Delay tpLH / tpHL (Max)	40ns, 40ns
Rise and Fall Time	9ns, 8ns
Supply Voltage - Operating	4.5 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	8-SO
Win Source Part Number	087807-HCPL-0721-500E
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	1,500
Family Name	HCPL-0721
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Singapore, Philippines
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian HCPL-0721-500E CAD Model

Description

The Broadcom Limited 087807-HCPL-0721-500E is an electronic component with push-pull/totem pole output type.

Data Rate: 25MBd
Isolation Voltage: 3750Vrms
Application: Isolators
Channel Output Current: 10mA
Quantity per Package: 1500
