HCNW3120-000E Real Image HCNW3120-000E Real Image
Same model may have multiple batches, images only for reference.
HCNW3120-000E Real Image HCNW3120-000E Real Image
HCNW3120-000E Real Image HCNW3120-000E Real Image
Same model may have multiple batches, images only for reference.

HCNW3120-000E

Part No HCNW3120-000E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description Optocoupler Drive Push-Pull 1-CH 30V 1500V 8-Pin PDIP W Tube / OPTOISO 5KV GATE DRIVER 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise and Fall Time 100ns, 100ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Forward Voltage 1.6V
Continuous forward current- Max 25mA
Supply Voltage - Operating 15 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting Through Hole
Case / Package 8-DIP
Approvals CSA, IEC/EN/DIN, UR
Win Source Part Number 016815-HCNW3120-000E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 42
Family Name HCNW3120
Introduction Date November 01, 2003
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCNW3120-000E CAD Model

Description

The Broadcom Limited 016815-HCNW3120-000E is an optical coupling technology-based isolator.

  • Mounting Type: Through-hole
  • Output Current: 2A (High), 2A (Low)
  • Forward Voltage: 1.6V
  • Channels: 1
  • Common-Mode Transient Immunity: 25kV/μs
  • Isolation Voltage: 5000Vrms
  • Peak Output Current: 2.5A
  • Pulse Width Distortion: 300ns
  • Propagation Delay: 500ns
  • Operating Temperature: -40°C to 100°C
  • Rise Time: 100ns
  • Fall Time: 100ns
  • Compliance: Halogen-free
  • Market Status: High demand and supply
