ASMT-AR00-ARS00 Broadcom Limited – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ASMT-AR00-ARS00

Part No ASMT-AR00-ARS00
Manufacturer Broadcom Limited
Catalog LED Lighting - Color
Description LED RED 628NM 1W 2SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Color Red
Wavelength 628nm (620nm ~ 635nm)
Current - Test 350mA
Voltage - Forward (Vf) (Typ) 2.1V
Lumens/Watt @ Current - Test 73 lm/W
Current - Max 500mA
Luminous Flux @ Current/Temperature 54lm (40lm ~ 62lm)
Temperature - Test 25°C
Viewing Angle 140°
Mounting Type Surface Mount
Case / Package 2-SMD, Gull Wing Exposed Pad
Supplier Device Package 2-SMD
Size / Dimension 0.315" Dia (8.00mm)
Height - Seated (Max) 0.165\
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1568641-ASMT-AR00-ARS00
Ultra Librarian 3D Model Ultra Librarian ASMT-AR00-ARS00 CAD Model
