Same model may have multiple batches, images only for reference.
AMMP-6120-BLK Real Image
Same model may have multiple batches, images only for reference.

AMMP-6120-BLK

Part No AMMP-6120-BLK
Manufacturer Broadcom Limited
Catalog RF Misc ICs and Modules
Description 8-24 GHZ FREQ MULTIPLIER X2 SMD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Features RF IC Frequency Multiplier DBS, VSAT 4GHz ~ 12GHz Output Power -11 to 5dBm 8-SMD (5x5)
Manufacturer Broadcom Limited
Package Tray
Part Status Obsolete
Mounting Surface Mount
Package 8-QFN
Case / Package 8-SMD (5x5)
MSL Level 2A (4 Weeks)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 516-1853, AMMP-6120-BLK-ND, AMMP6120BLK, Q2313336
Quantity per package 10
Popularity High
Supply and Demand Status Balance
Win Source Part Number 911403-AMMP-6120-BLK
Ultra Librarian 3D Model Ultra Librarian AMMP-6120-BLK CAD Model

Description

The Broadcom Limited 911403-AMMP-6120-BLK is an RF IC frequency multiplier that is commonly used in DBS and VSAT applications.

  • Output Power: -11 to 5dBm
  • Frequency Range: 4GHz to 12GHz
  • Package: Surface Mount
  • Case/Package: 8-QFN, 8-SMD (5x5)
  • Category: RF/IF and RFID
  • Product Status: Obsolete
  • Supply and Demand Status: Balanced
  • Package Quantity: 10
