ACPL-M50L-500E Real Image ACPL-M50L-500E real image580
Same model may have multiple batches, images only for reference.
ACPL-M50L-500E Real Image ACPL-M50L-500E real image580
ACPL-M50L-500E Real Image ACPL-M50L-500E real image580
Same model may have multiple batches, images only for reference.

ACPL-M50L-500E

Part No ACPL-M50L-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 5-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 3mA
Maximum DC Current Transfer Ratio 200% @ 3mA
Switching Turn-On and Turn-Off Time 200ns, 380ns
Input Type DC
Output Type Transistor
Maximum Output Voltage 24V
Channel Output Current 8mA
Forward Voltage 1.5V
Continuous forward current- Max 20mA
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 5-SO
Win Source Part Number 039079-ACPL-M50L-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian ACPL-M50L-500E CAD Model

Description

Overview of ACPL-M50L-500E

The ACPL-M50L-500E is a high-performance optocoupler designed to provide superior insulation protection and signal transmission accuracy. It is an ideal solution for applications requiring electrical isolation while maintaining a compact form factor.

Key Features and Benefits

  • High Insulation Voltage: Offers reliable insulation up to 5000 Vrms, ensuring safety in high-voltage applications.
  • Wide Temperature Range: Functions efficiently in temperature ranges from -55°C to +110°C.
  • Compact Design: Supports space-constrained applications with its small footprint.

Applications

  • Switching power supplies
  • DC-DC converters
  • Industrial signal isolation
  • Motor control circuits
