ACPL-K43T-500E Real Image ACPL-K43T-500E real image20950
Same model may have multiple batches, images only for reference.
ACPL-K43T-500E Real Image ACPL-K43T-500E real image20950
ACPL-K43T-500E Real Image ACPL-K43T-500E real image20950
Same model may have multiple batches, images only for reference.

ACPL-K43T-500E

Part No ACPL-K43T-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Automotive R2CouplerTM Wide Operating Temperature | OPTOISOLATOR 5KV TRANSISTOR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tape and Reel
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Minimum) 32% at 10mA
Current Transfer Ratio (Maximum) 100% at 10mA
Turn On / Turn Off Time 150ns, 500ns
Input Type DC
Output Type Transistor
Maximum Output Voltage 20V
Current - Output / Channel 8mA
Voltage - Forward (Vf) 1.55V
Current - DC Forward (If) (Maximum) 20mA
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 8-SOIC (0.268", 6.81mm Width)
Supplier Device Package 8-SO
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Win Source Part Number 729368-ACPL-K43T-500E
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ACPL-K43T-500E CAD Model

Description

The ACPL-K43T-500E is a transistor output type isolation amplifier manufactured by Broadcom Limited. It has a maximum output voltage of 20V and a voltage isolation of 5000Vrms.

  • Output Type: transistor
  • Maximum Output Voltage: 20V
  • Voltage Isolation: 5000Vrms
  • Package: 8-SO
  • Current Output per Channel: 8mA
  • Temperature Range: -40°C to 125°C
  • Manufacturer Pack Quantity: 1,000
