ACPL-344JT-500E Real Image ACPL-344JT-500E real image15007 ACPL-344JT-500E real image15008
Same model may have multiple batches, images only for reference.
ACPL-344JT-500E Real Image ACPL-344JT-500E real image15007 ACPL-344JT-500E real image15008
ACPL-344JT-500E Real Image ACPL-344JT-500E real image15007 ACPL-344JT-500E real image15008
Same model may have multiple batches, images only for reference.

ACPL-344JT-500E

Part No ACPL-344JT-500E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 5KV GATE DRIVER 16SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Technology Optical Coupling
Number of Channels 1
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 50kV/μs
Propagation Delay tpLH / tpHL (Max) 250ns, 250ns
Pulse Width Distortion (Max) 100ns
Rise and Fall Time 70ns, 50ns
Current - Output High, Low 0.75A, 1A
Current - Peak Output 2.5A
Forward Voltage 1.55V
Continuous forward current- Max 20mA
Supply Voltage - Operating 15 V to 25 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 16-SO
Approvals CSA, IEC/EN/DIN, UR
Win Source Part Number 1011679-ACPL-344JT-500E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 850
Ultra Librarian 3D Model Ultra Librarian ACPL-344JT-500E CAD Model

Description

The 1011679-ACPL-344JT-500E from Broadcom Limited is an optical coupling technology device with one channel.

  • Channels: 1
  • Forward Voltage: 1.55V
  • Isolation Voltage: 5000Vrms
  • Current Output High: 0.75A
  • Current Output Low: 1A
  • Peak Output: 2.5A
  • Common Mode Transient Immunity: 50kV/μs
  • Propagation Delay tpLH / tpHL (Max): 250ns, 250ns
  • Mounting: Surface-Mount (SMD)
  • Package: 16-SO
  • Temperature Range: -40°C to 125°C
  • Supply Voltage: 15V to 25V
  • Rise Time: 70ns
  • Fall Time: 50ns
  • Supply and Demand Status: balanced
  • Units per Package: 850
