SRR4018-3R3Y Real Image
Same model may have multiple batches, images only for reference.

SRR4018-3R3Y

Part No SRR4018-3R3Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 3.3UH 1.95A 65MOHM SMD / 3.3 µH Shielded Drum Core, Wirewound Inductor 1.95 A 65mOhm Max 1919 (4848 Metric)
Datasheet
SRR4018-3R3Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRR4018
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 3.3 µH
Tolerance ±30%
Current Rating (Amps) 1.95 A
Current - Saturation (Isat) 1.8A
Shielding Shielded
DC Resistance (DCR) 65mOhm Max
Q @ Freq 8 @ 7.96MHz
Frequency - Self Resonant 61MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case 1919 (4848 Metric)
Dimension 0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max) 0.079" (2.00mm)
Base Product Number SRR4018
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Other Names SRR40183R3Y,-SRR4018-3R3Y,-SRR4018-3R3YCT,SRR4018-3R3YDKR,SRR4018-3R3YCT,-SRR4018-3R3Y-ND,SRR4018-3R3Y-ND,SRR4018-3R3YTR,-SRR4018-3R3YTR
Standard Package 800
Win Source Part Number 995874-SRR4018-3R3Y
Ultra Librarian 3D Model Ultra Librarian SRR4018-3R3Y CAD Model

Description

The SRR4018-3R3Y is a fixed inductor with an inductance of 3.3µH and a current rating of 1.95A.

  • Inductance: 3.3µH
  • Current Rating: 1.95A
  • Q @ 7.96MHz: 8
  • Frequency of Self-Resonant: 61MHz
  • Shielding: Shielded
  • Mounting: SMD (SMT)
  • Packaging: Tape and Reel
  • Standard Package: 800
  • Tolerance: ±30%
  • Material Core: Ferrite
  • DC Resistance: 65mOhm max
  • Temperature Range: -40°C to 125°C
  • Series: SRR4018
  • Manufacturer: Bourns Inc.
