SRP7030-R56FM Real Image
Same model may have multiple batches, images only for reference.

SRP7030-R56FM

Part No SRP7030-R56FM
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 560NH 15A 5 MOHM SMD / Shielded Power Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Bourns Inc.
Packaging Reel
Part Status Obsolete (End Of Life)
Type Molded
Material - Core Iron
Inductance 560nH
Tolerance ±20%
Current Rating (Amps) 15A
Current - Saturation 17A
Shielding Shielded
DC Resistance (DCR) 5mOhm Max
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 100kHz
Mounting Style SMD
Manufacturer Package Nonstandard
Dimension 0.299" L x 0.256" W (7.60mm x 6.50mm)
Height - Seated (Maximum) 0.118" (3.00mm)
Part Number Series SRP7030
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 807432-SRP7030-R56FM
Ultra Librarian 3D Model Ultra Librarian SRP7030-R56FM CAD Model

Description

The Bourns Inc. SRP7030-R56FM inductor is a molded, shielded component.

  • Inductance: 560nH
  • Tolerance: ±20%
  • Core Material: Iron
  • Current Saturation: 17A
  • DC Resistance: 5mOhm maximum
  • Operating Temperature: -55°C to 125°C
  • Case/Package: Nonstandard
  • Height: 0.118 inches when seated
  • Popularity: Medium
  • REACH Status: Unaffected
  • Current Rating: 15A
  • Status: Obsolete (end of life)
  • Package: Reel
  • Manufacturer Pack Quantity: 1,000
