Same model may have multiple batches, images only for reference.
SRP7030-R20M Real Image
Same model may have multiple batches, images only for reference.

SRP7030-R20M

Part No SRP7030-R20M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 200NH 24A 3 MOHM SMD / Shielded Power Inductors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Bourns Inc.
Packaging Reel
Type Wirewound
Material - Core Iron
Inductance 200nH
Tolerance ±20%
Current Rating (Amps) 24A
Current - Saturation 36A
Shielding Shielded
DC Resistance (DCR) 3mOhm Max
Temperature Range - Operating -55°C ~ 150°C
Inductance Frequency - Test 100kHz
Mounting Style SMD
Manufacturer Package Nonstandard
Dimension 0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Maximum) 0.126" (3.20mm)
Part Number Series SRP7030
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803697-SRP7030-R20M
Ultra Librarian 3D Model Ultra Librarian SRP7030-R20M CAD Model

Description

The Bourns Inc. SRP7030-R20M is a shielded wirewound type SMD inductor.

  • Inductance: 200nH ±20%
  • Core Material: Iron
  • DC Resistance: 3mOhm Max
  • Current Saturation: 36A
  • Operating Temperature Range: -55°C to 150°C
  • Dimension: 0.307" L x 0.276" W (7.80mm x 7.00mm)
  • Manufacturer Package: Nonstandard
  • Supply and Demand Status: Balanced
  • Popularity: Popular
