MF-MSMF110/24X-2 Real Image MF-MSMF110/24X-2 real image MF-MSMF110/24X-2 label picture
Same model may have multiple batches, images only for reference.
MF-MSMF110/24X-2 Real Image MF-MSMF110/24X-2 real image MF-MSMF110/24X-2 label picture
MF-MSMF110/24X-2 Real Image MF-MSMF110/24X-2 real image MF-MSMF110/24X-2 label picture
Same model may have multiple batches, images only for reference.

MF-MSMF110/24X-2

Part No MF-MSMF110/24X-2
Manufacturer Bourns Inc.
Catalog PTC Resettable Fuses
Description PTC Resettable Fuse 1.1A(hold) 2.2A(trip) 24V 20A 0.8W 0.5s 0.06Ohm SMD Solder Pad 1812 T/R Automotive / FUSE PTC RESET 1.10A SMD 1812
Datasheet
MF-MSMF110/24X-2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Polymeric
Voltage - Max 24V
Current - Max 20A
Current - Hold (Ih) (Max) 1.1A
Current - Trip (It) 2.2A
Time to Trip 500ms
Resistance - Initial (Ri) (Min) 60 mOhm
Resistance - Post Trip (R1) (Max) 180 mOhm
Temperature Range - Operating -40°C to 85°C
Ratings AEC-Q200
Mounting SMD (SMT)
Dimension 0.181" L x 0.128" W (4.60mm x 3.24mm)
Thickness (Max) 0.033" (0.85mm)
Approvals cURus, TUV
Win Source Part Number 023191-MF-MSMF110/24X-2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automotive, Computers & Computer Peripherals, Defence, Military & Aerospace
Family Name MF-MSMF
Introduction Date January 01, 2000
ECCN EAR99
Country of Origin United Kingdom
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MF-MSMF110/24X-2 CAD Model

Description

The MF-MSMF110/24X-2 is a polymeric type circuit protection component manufactured by Bourns Inc.

  • Design: meet specific requirements
  • Reliability: highly reliable
  • Versatility: versatile
  • Applications: automotive, computers, computer peripherals, defense, military, and aerospace
  • Status: active product
  • Supply and Demand Status: sufficient
