MF-MSMD020-2 Bourns Inc.
Same model may have multiple batches, images only for reference.

MF-MSMD020-2

Part No MF-MSMD020-2
Manufacturer Bourns Inc.
Catalog PTC Resettable Fuses
Description FUSE RESETTABLE .20A HOLD SMD
Datasheet
MF-MSMD020-2 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Obsolete(EOL)
Type Polymeric
Voltage - Max 30V
Current - Max 80A
Current - Hold (Ih) (Max) 200mA
Current - Trip (It) 400mA
Time to Trip 60ms
Resistance - Initial (Ri) (Min) 400 mOhm
Resistance - Post Trip (R1) (Max) 6 Ohm
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Dimension 0.179" L x 0.027" W (4.55mm x 0.68mm)
Thickness (Max) 0.134" (3.41mm)
Approvals CSA, TUV, UR
Win Source Part Number 099011-MF-MSMD020-2
Ultra Librarian 3D Model Ultra Librarian MF-MSMD020-2 CAD Model

Description

The Bourns Inc. 099011-MF-MSMD020-2 is a polymeric type circuit protection component that has CSA, TUV, and UR approvals.

  • Maximum Thickness: 0.134 inches (3.41mm)
  • Maximum Voltage: 30V
  • Maximum Current: 80A
  • Current Hold (Ih): 200mA
  • Current Trip (It): 400mA
  • Time to Trip: 60ms
  • Mounting: SMD (SMT)
  • Temperature Range: -40°C to 85°C
  • Dimension: 0.179 inches L x 0.027 inches W (4.55mm x 0.68mm)
  • Initial Resistance (Ri): 400 mOhm
  • Post-Trip Resistance (R1): 6 Ohm
  • Resistance @ 25°C (Typ): -
