CDSOT23-T05 Real Image CDSOT23-T05 Real Image1 CDSOT23-T05 Real Image2
Same model may have multiple batches, images only for reference.
CDSOT23-T05 Real Image CDSOT23-T05 Real Image1 CDSOT23-T05 Real Image2
CDSOT23-T05 Real Image CDSOT23-T05 Real Image1 CDSOT23-T05 Real Image2
Same model may have multiple batches, images only for reference.

CDSOT23-T05

Part No CDSOT23-T05
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 5VWM 13.5VC SOT23-3
Datasheet
CDSOT23-T05 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Bourns Inc.
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5V
Voltage - Breakdown (Min) 6V
Voltage - Clamping (Max) @ Ipp 13.5V
Current - Peak Pulse (10/1000µs) 42A (8/20µs)
Power - Peak Pulse 500W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 350pF @ 1MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23-3
Base Product Number CDSOT23
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 578246-CDSOT23-T05
Ultra Librarian 3D Model Ultra Librarian CDSOT23-T05 CAD Model

Description

The 578246-CDSOT23-T05 is a Zener type transient voltage suppressor (TVS) diode designed for general-purpose circuit protection.

  • Type: Zener TVS Diode
  • Packaging: Tape & Reel
  • Reverse Standoff Voltage: 5V
  • Breakdown Voltage: 6V
  • Clamping Voltage: 13.5V @ 500W
  • Mounting Style: Surface Mount
  • Operating Temperature: -55°C to 150°C
  • Manufacturer: Bourns Inc.
  • Product Status: Active
  • REACH: Unaffected
  • California Prop 65 Warning: Yes
