CDSOD323-T24SC Real Image CDSOD323-T24SC Real Image1 CDSOD323-T24SC Real Image2 CDSOD323-T24SC Real Image3 CDSOD323-T24SC Real Image4
Same model may have multiple batches, images only for reference.
CDSOD323-T24SC Real Image CDSOD323-T24SC Real Image1 CDSOD323-T24SC Real Image2 CDSOD323-T24SC Real Image3 CDSOD323-T24SC Real Image4
CDSOD323-T24SC Real Image CDSOD323-T24SC Real Image1 CDSOD323-T24SC Real Image2 CDSOD323-T24SC Real Image3 CDSOD323-T24SC Real Image4
Same model may have multiple batches, images only for reference.

CDSOD323-T24SC

Part No CDSOD323-T24SC
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 24VWM 46.2VC SMD
Datasheet
CDSOD323-T24SC Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Bourns Inc.
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 1
STAND-OFF Voltage (Vwm) 24V
Minimum Breakdown Voltage 26.7V
Max Clamping Voltage 46.2V (Typ)
Peak Pulse Current(Ippm) 9A (8/20μs)
Power Dissipation - Pd 400W
Applications General Purpose
Capacitance @ Frequency 40pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-323
Win Source Part Number 1029000-CDSOD323-T24SC
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian CDSOD323-T24SC CAD Model

Description

The 1029000-CDSOD323-T24SC is a surface-mount device (SMD) zener diode with 1 bidirectional channel from Bourns Inc.

  • Mounting Type: SMD
  • Number of Channels: 1 Bidirectional
  • Capacitance: 40pF @ 1MHz
  • Application: General Purpose
  • Stand-Off Voltage (Vwm): 24V
  • Minimum Breakdown Voltage: 26.7V
  • Maximum Clamping Voltage: 46.2V (Typ)
  • Peak Pulse Current (Ippm): 9A (8/20μs)
  • Power Dissipation - Pd: 400W
  • Package: SOD-323
