Same model may have multiple batches, images only for reference.

SRU1048-220Y

Name: SRU1048-220Y
Brand: Bourns Inc.
SKU: 1328025
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRU1048-220Y
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Description	FIXED IND 22UH 2.6A 42 MOHM SMD / 22 µH Shielded Drum Core, Wirewound Inductor 2.6 A 42mOhm Nonstandard
Datasheet	SRU1048-220Y Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Manufacturer	Bourns Inc.
Packaging	Reel - TR
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	22 µH
Tolerance	±30%
Current Rating (Amps)	2.6 A
Current - Saturation (Isat)	2A
Shielding	Shielded
DC Resistance (DCR)	42mOhm
Q @ Freq	22 @ 2.52MHz
Frequency - Self Resonant	12MHz
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	Surface Mount
Case / Package	Nonstandard
Size / Dimension	0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max)	0.201" (5.10mm)
Base Product Number	SRU1048
RoHS Status	ROHS3 Compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Other Part Number	SRU1048220Y,-SRU1048-220Y,SRU1048-220YTR,SRU1048-220YCT,-SRU1048-220YTR,-SRU1048-220YCT
Standard Package	600
Win Source Part Number	1328025-SRU1048-220Y
Ultra Librarian 3D Model	Ultra Librarian SRU1048-220Y CAD Model

Alternative Products

Description

This is a Bourns Inc. fixed inductor with an inductance of 22 µH and a current rating of 2.6 A.

Tolerance: ±30%
DC Resistance (DCR): 42mOhm
Type: drum core, wirewound
Shielding: shielded
Size: 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height: 0.201" (5.10mm)
Mounting: surface mountable
Packaging: reel
Standard Package: 600
REACH: unaffected
ROHS3 compliant: Yes
