Same model may have multiple batches, images only for reference.

SRU1028A-560Y

Name: SRU1028A-560Y
Brand: Bourns Inc.
SKU: 1273156
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SRU1028A-560Y
Manufacturer	Bourns Inc.
Catalog	Fixed Inductors
Datasheet	SRU1028A-560Y Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Bourns Inc.
Series	SRU1028A
Package	Tape & Reel
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	56 µH
Tolerance	±30%
Current Rating (Amps)	1.1 A
Current - Saturation (Isat)	1A
Shielding	Shielded
DC Resistance (DCR)	270mOhm Max
Q @ Freq	22 @ 2.52MHz
Frequency - Self Resonant	10MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	100 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard
Dimension	0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max)	0.122" (3.10mm)
Base Product Number	SRU1028A
Other Names	SRU1028A-560YDKR,SRU1028A-560YCT,SRU1028A-560YTR,SRU1028A-560Y
Standard Package	1,000
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Win Source Part Number	1273156-SRU1028A-560Y
Ultra Librarian 3D Model	Ultra Librarian SRU1028A-560Y CAD Model

Alternative Products

Description

The Bourns Inc. SRU1028A-560YDKR is a drum core, wirewound inductor.

Shielding: Yes
Tolerance: ±30%
Package: Tape and Reel
Inductance: 56μH
Maximum Height: 0.122"
Standard Package: 1,000
Mounting Type: SMD (SMT)
AEC-Q200 Rated: Yes
Material-Core: Ferrite
Q @ Freq: 22 @ 2.52MHz
Frequency-Self Resonant: 10MHz
Package/Case: Nonstandard
DC Resistance (DCR): 270mOhm Max
Temperature Range: -40°C ~ 125°C
Dimension: 0.394" L x 0.394" W (10.00mm x 10.00mm)
Current Rating (Amps): 1.1A
Inductance Frequency-Test: 100 kHz
REACH Status: REACH Unaffected
